New air diffuser: greater performance, lower consumption
DESCRIPTION
Hind over row pneumatic deleafer, double row, 4 blowing heads (2x2), work on 2 complete rows, pendulum frame, self-centring guidance on the leaves wall, 6 hydraulic movements with electrohydraulic joystick, leaning wheels and skids, 30° frame tilting, cardan, hind 3 point hitching, with oil cooler kit. High operational yield.
TECHNICAL FEATURES
Min. required tractor power | 100 HP |
---|---|
PTO | 750 rpm |
Weight | 1000 Kg |
Working speed | from 4 to 6 Km/h depending on the working conditions |
PressioWorking pressure ne di lavoro | from 0,5 to 0,9 bar (adjustable with tractor’s PTO) |
FUNCTIONING
The air produced by a compressor reaches the rotors, hits the leaves in the surrounding grape’s area in the whole deepness. A selective defoliation in the fruiting zone is obtained.
ADVANTAGES
PHOTO GALLERY
JOB DONE
VIDEO
